The assembly of components from 1 good:
CPU
| Type of | Intel Motherboards |
| Socket connector (SOCKET) | LGA1151 |
| Processors | Threadripper processors |
| Chipset (North Bridge) | Intel B150 |
RAM
| Type of memory | DDR4 DIMM |
| Compatible RAM | DDR4 for PC |
| Number of memory slots | 4 |
| TOMAL CHANNals | 2 |
| Max. memory size | 64 |
| Maximum memory frequency | 2133 |
Communications
| Network adapter (LAN) | 1000 Mbps |
| Wi-Fi wireless module | - |
| Bluetooth module | - |
Sound
| Sound card | Realtek ALC887 |
| Sound scheme | 7.1 |
Built -in ports
| The number of Sata III | 6 |
| Number PCI-E 1x | 2 |
| Number PCI-E 16X | 1 |
| Support PCI-E 16X V2.0 | + |
| Support PCI-E 16X V3.0 | + |
| Number of internal USB 2.0 | 11 |
| Number of internal USB 3.0 | 4 |
| Number of internal USB 3.1 | 1 |
| COM COM (RS-232) | 1 |
| SLI or Crossfire support | - |
External ports
| PS/2 connector | + |
| Number of external USB 2.0 | 5 |
| Number of external USB 3.0 | 2 |
| VGA connector | + |
| DVI-D connector | + |
| HDMI connector | + |
| DisplayPort connector | - |
| Output s/pdif | + |
Form factor
| Form factor | microATX |
| Compatibility with the body | Corps |
